WWI U-boat Types


Type U 2

Gasoline-powered boats class


Construction history of type U 2

U-boats# ShipyardWerk #Built during
U 2Kaiserliche Werft, Danzig11906 - 1908

All U-boats of type U 2

Below are the 1 commissioned U-boats of this type.

U 2

Technical information for type U 2

Displacement:
(tons)
341 (sf)
430 (sm)
(total)
Length: (m)45,42 oa
39,30 ph
Beam: (m)5,50 oa
3,40 ph
Draught: (draft)3,05 m
Height:6,62 m
Power: (hp)600 (sf)
630 (sm)
Speed:
(knots)
13,2 (sf)
9,0 (sm)
Range:
(miles / knots)
1600/13 (sf)
50/5 (sm)
Torpedoes:6
2/2 (bow / stern tubes)
Mines:No mines carried
Deck gun:No deck gun
Crew:22 men
Max depth:ca. 30 m
(98 feet)
sm = submerged, sf = surfaced, ph = pressure hull,
oa = overall, hp = horsepower.
